Garbage bag making machine
The Garbage Bag Making Machine utilizes a step motor or a servo motor for the feeding process, with a computer system managing the machine’s speed. Users can conveniently adjust the bag size via the computer interface. This machine is specifically engineered for the fabrication of perforated core-less bags on rolls and rolling bags with a core. It is adept at producing double line Star sealing T-shirt bags, vegetable bags, table sheet cloths, and garbage bags. Furthermore, it is equipped with a printing photocell, enabling the production of printed bags on rolls. This model is capable of simultaneously manufacturing bags on two lines, and its user-friendly design facilitates ease of operation.

| Model | KDB-500H |
| bag making speed | 30-190pcs/min |
| Length of bag making | 100-1200mm |
| Width of bag making | 60-300mm |
| Thickness of bag making | 0.005-0.015mm |
| Bag making methods | Flat open bag with core |
| Material feeding | AC motor with inverter control |
| Bag length control | Servo motor ,China brand 3kw |
| Main motor | 1.5kw with inverter control |
| Heating power | 2kw |
| Total power | 8kw |
| Machine size | 6000*1300*1800mm |

Our Main parts cooperator as following brand,but standard parts all made from China.
